R&S provides a wide-range of underground parking doors which are uniquely tailored to enhance safety, security, and convenience for residents, visitors, or employees, ensuring seamless access and peace of mind in parking facilities.
Manufacturers R&S Services & Installs
High Speed Doors
Hörmann HDLH
Low headroom parking door
Designed for parking garages where extremely reliable, high cycle operation is a must; all the same dependable HD Series features plus a low headroom design are wrapped into one.
This high-performance rubber door is best suited for any application where headroom clearance is very limited; between 13 and 18 inches. It has a patented aluminum bottom bar with knock-away pivot arms designed to take full impacts with little or no downtime and is easily reset from the floor without the use of special tools or parts. The Model HDLH includes a high efficiency helical gear head operator with a multi-function capacity PLC (programmable logic controller) and offers door speeds up to 30 inches per second.
For an added level of visibility and safety, our LED Lite-Advance door monitoring system, which is daylight visible with red / green light signals, is included as standard equipment in all HD SERIES door models.
Features
High Speed: Opening speed: Up to 30″ per second*. Opening time: 3.52 seconds*
Low Maintenance: Springless, quick reset & withstands harsh enviornments
Impact: Breakaway (quick reset/repair)
Max/Min Dimensions: 7′-0″ up to 25′-0″ wide. 6′-0″ up to 10′-0″ high (low headroom 13″).
Hörmann Steel Ranger 9000LH
HIgh performance limited headroom rolling steel door
The perfect alternative to outdated rolling steel doors in high-cycle locations. Springless, direct-drive, and fast (opening speed of 45 inches per second), the Steel Ranger™ 9000 LH accommodates door openings with limited clearance above the opening. It’s built for high cycles, so maintenance requirements and costs are minimal, supporting a low cost of ownership.
Springless Design for Maintenance-Free Operation
Because it’s springless, the Steel Ranger™ fits into even the most confined locations, with compact guide tracks that require only 4” of side room. In addition, the LH low headroom design requires only 19 inches of clearance above the door opening, while patented noise reduction panel pads promote quiet operation.
Features
High Speed: Opening speed: Up to 45″ per second*. Opening time 3 seconds*.
Low Maintenance: Springless, fewer moving parts, designed for interior or exterior environments.
Impact: Non-break-away
Max/Min Dimensions: 3′-5″ up to 21′-4″ wide x 9′-1″ high
Tilt Up Gates
Product Information Coming Soon!
